Condensate neutralisation for gas and oil condensing boiler
These condensate neutralisation systems are used for neutralisation (pH value increase above 6.5) of condensate from gas or oil-fired condensing boilers and / or their flue gas systems made of stainless steel, plastic, graphite, glass and ceramics. They each consist of: a neutralisation box made of plastic with integrated settling zone for impurities, pH indicator strips, connection hose and connecting accessories.
GENO-Neutra
|
KW35 | KW65 |
|---|---|---|
| Gas condensate up to max. [l / h] | 4.9 | 9.1 |
| Boiler capacity at 0.14 l / kW max. [kW] | 35 | 65 |
| Condensate temperature [°C] | 5 - 60 | 5 - 60 |
| Inlet/outlet hose [DN] | 20 | 20 |
| Height inlet/outlet [mm] | 61 | 61 |
| Condensate backwater height [mm] | 90 | 90 |
| GENO-Neutralit Hz filling volume [kg] | 2.5 | 3.3 |
| Order no. | 410335 | 410345 |
